This model's single-sided composite electrode, which is of the A117 series, has a nominal thickness of 125um and a width of 250mm.
This model is a dry electrode series with a high capacity. It works especially well with portable electronics and large-scale energy storage applications. The High Capacity Series fosters innovation and sustainable development while meeting strict power demand standards in a variety of applications, including wind energy, solar energy storage, and everyday electronics.
Electrode sheet model | TY-125S-250-A117 |
Electrode sheet type | Single-sided |
Electrode sheet thickness | 125±5 μm |
Compaction density of the electrode sheet | ≥0.66g/cm3 |
Moisture content of the electrode sheet | ≤4% |
Total width of the electrode sheet | 250±1mm |
Width of the coated part of the electrode sheet and its tolerance | 240±2.0mm |
Width of the single-sided blank area | 5mm±1 |
Thickness of the foil and its tolerance | 20±2um |
Reference for capacitance performance in capacitors | 2160F/㎡ |
Meet the environmental protection requirements such as RoHS. | |
1. Powerful Output Power, Stable and Reliable
The optimized electrode design endows it with powerful output power, enabling it to stably supply large currents. It is applicable to equipment with high power requirements, such as electric tools and automobiles.
2. Reducing Internal Resistance to Enhance Efficiency
The unique dry manufacturing process significantly reduces the internal resistance and improves the energy conversion efficiency, ensuring the maximum performance and long-lasting performance of the battery.
3. Improving Safety and Reducing Risks
The dry electrodes adopt solvent-free and low-temperature processes, reducing the safety risks caused by high temperatures and chemical reactions and enhancing the safety of the overall system.
The TY-125S-250-A117 dry electrode is widely used in dash cams, car phone holders, and toys when combined with a high-capacity leaded capacitor. Given the increasing complexity of electric toys, a reliable power source is essential in the toy industry. By guaranteeing that toys like robots and racing cars run smoothly and avoiding the inconvenience of frequent battery replacements, the capacitor offers strong and long-lasting power. The built-in capacitor in automotive phone holders allows the phone to be continuously charged during drives when navigation is crucial. It ensures continuous navigation by maintaining a constant voltage even when a vehicle starts and stops. For dash cams, which need to be recorded all the time, the high-capacity capacitor provides dependable power. It protects owners' rights and preserves evidence for accident investigations by preventing data loss from power outages during lengthy travel. Thus, this electrode and capacitor combination successfully meets a variety of customer needs.
