Snap-In Supercapacitor 2.7V 350F

Name: Snap-In Supercapacitor 2.7V 350F
Brand: Shenzhen Tsingyan Electronic Technology Co., Ltd.

The Snap-In Supercapacitor 2.7V 350F is essential for smart water meters, small electronic scales, and children’s smart toys. It provides instantaneous power during water pressure fluctuations, ensuring accurate data for billing. In portable scales, it prevents sudden power loss, ensuring stable data display. For children’s toys, it offers extra energy, maintaining lights and sounds, and extending playtime.

Buy Snap-In Supercapacitor 2.7V 350F

Parameters of Snap-In Supercapacitor 2.7V 350F

NO.	Item	Specification	Remark
1	Rated Capacitance	350F	Test methods are described below.
2	Rated Voltage	2.7V
3	Capacitance Tolerance	-10%~+20%	@25℃
4	Surge Voltage	2.85V
5	ESRAC	≤ 3.0mΩ	1kHz@25℃
6	ESRDC	≤ 4.0mΩ	Test temperature: 25±2℃
7	Standard Charging Current	3.8A	@25℃ Charge at 3.8(A) constant current to the rated voltage.
8	Standard Discharging Current	3.8A	@25℃ Discharge at 3.8(A) constant current to the half of rated voltage.
9	Power density	3.12kW/kg
10	Dump energy	0.35Wh
11	Voltage Holding	≥80%	25℃, After 72 hours
12	Operating Temperature Range	-40~65℃
13	Storage Temperature Range	-20~50℃
14	Maximum operating current	24A
15	Weight	about 70g
16	Leakage Current	≤ 0.9mA	@25℃
17	Maximum peak current	196.9A

Advantages of Snap-In Supercapacitor 2.7V 350F

1. High Energy Density

Offers higher energy storage, ideal for small power devices.

2. Rapid Charge/Discharge

Supports fast charging and discharging, meeting high-frequency usage demands.

3. Compact and Lightweight

Compact design, easy installation, perfect for space-constrained devices.

Application of Snap-In Supercapacitor 2.7V 350F

Smart Water Meters: Smart water meters need to accurately measure water usage data. During fluctuations in water pressure or brief water supply interruptions, the 2.7V 350F supercapacitor can provide instantaneous power to ensure the proper functioning of the meter's electronic components, preventing data loss. This enables accurate billing and provides reliable data for water consumption management.

Small Electronic Scales: Portable electronic scales are designed to be compact and lightweight. This supercapacitor can assist with power supply when the battery is low, preventing sudden power loss during weighing operations. It ensures stable data display for frequent weighing needs in commercial stalls or home kitchens.

Children's Smart Toys: Some simple interactive children's toys, such as light-up and sound-emitting educational puzzles, have low power consumption but require a stable power supply. This supercapacitor provides extra energy when the battery is low, ensuring lights and sounds continue, and extending playtime for children.
