No. | Item | Specifications |
1 | Electrostatic capacity | 12857F/42Ah |
2 | Nominal capacity | ≥42Ah(17.5-29.4V) |
3 | Module composition | HESC 4.2V/15000F 7S6P |
4 | Nominal voltage | 28V |
5 | Surge voltage | 29.4V |
6 | Minimum working voltage | 17.5V |
7 | Internal AC Resistance | ≤2.5mΩ@25℃ |
8 | Internal DC Resistance | ≤3.8mΩ@25℃ |
9 | Energy capacity(Fully Charged) | 984.9Wh |
10 | Standard charging and discharging current | 40A |
11 | Maximum discharge current | 1000A/10S |
12 | Storage voltage Range | 23.52V(±2%) |
13 | Cycle life | 50000 times |
14 | Operation temperature | -40℃~65℃ |
15 | Storage temperature | -20℃~45℃ |
16 | Communication Interface | RS485/CAN |
17 | Communication Protocol | Modbus RTU |
1.High Energy Density and Strong Energy Storage
With a capacity of 12857F and a nominal voltage of 28V, it provides ample energy reserves.
2.Superior Charge and Discharge Performance
Low internal resistance, standard current of 40A, and a maximum discharge current of up to 1000A/10S.
3.Good Temperature Adaptability
Operating temperature range from -40°C to 65°C, capable of working in both high and low temperature environments.
Emergency and Transportation Fields
As a low-temperature emergency starting power supply, it provides a powerful starting current for diesel generators in low-temperature environments, ensuring their smooth start-up, and is suitable for various scenarios requiring backup power. - Used in low-speed unmanned vehicles, logistics vehicles, and electric bicycles, it enhances the power during starting, accelerating, and climbing, recovers braking energy, and extends the driving range.
Industrial and Power System Fields
Acting as a backup power supply, it ensures the continuous operation of key equipment such as industrial equipment and communication base stations during power outages or voltage fluctuations, preventing data loss and production interruption. - Applied in energy storage systems, it can balance energy supply and demand and improve efficiency; used in dynamic voltage restorers to stabilize the grid voltage and participate in primary frequency regulation to enhance the stability of the power grid.
Automation Equipment Field
Provides reliable power for mobile robot AGVs, meets their high-power requirements during operation, and helps improve the efficiency of industrial automation production.
