Axial Supercapacitor 2.7V 3000F

Name: Axial Supercapacitor 2.7V 3000F
Brand: Shenzhen Tsingyan Electronic Technology Co., Ltd.

With its revolutionary powder film-forming method, the Tsingyan axial supercapacitor uses a dry electrode, giving the supercapacitor monomer its high energy density, extended service life, and environmental protection. It satisfies the market's need for high-performance and low-energy-consumption energy storage devices and is highly appropriate for use in industries including electric vehicles, renewable energy storage, and fast charging equipment.

Buy Axial Supercapacitor 2.7V 3000F

Parameters of Axial Supercapacitor 2.7V 3000F

NO.	Item	Specification	Remark
1	Rated Capacitance	3000F	Test methods are described below.
2	Rated Voltage	2.7V
3	Capacitance Tolerance	-10%~+20%	@25℃
4	Surge Voltage	2.85V
5	ESRDC	≤ 0.29mΩ	Test temperature: 25±2℃
6	Standard Charging Current	100A	@25℃ Charge at 100(A) constant current to the rated voltage.
7	Standard Discharging Current	60A	@25℃ Discharge at 100(A) constant current to the half of rated voltage.
8	Power Density	6.03kW/kg
9	Dump Energy	3.04Wh
10	Voltage Holding	≥80%	25℃, After 72 hours
11	Operating Temperature Range	-40~65℃
12	Storage Temperature Range	-20~50℃
13	Maximum Operating Current	210A
14	Weight	about 0.50kg
15	Leakage Current, LC(72h)	≤ 5.2mA	@25℃
16	Maximum Peak Current, 1s	2165.8A

Advantages of Axial Supercapacitor 2.7V 3000F

1. Long-Lasting and Stable Power Supply

Its high capacitance ensures a stable and reliable power supply, even under varying load conditions.

2. High Power Output and Rapid Discharge

Designed for applications requiring rapid energy discharge, making it ideal for electric vehicles and high-power industrial equipment.

3. Superior Thermal Stability

Advanced thermal management ensures consistent performance even in high-temperature environments.

Application of Axial Supercapacitor 2.7V 3000F

Solar Microinverters

In distributed solar power systems, microinverters are responsible for converting DC power from solar panels to AC power. The 2.7V 3000F supercapacitor stores excess energy generated by solar panels during peak sunlight and provides brief power to the microinverter during periods of insufficient light or at night, ensuring stable and continuous operation and guaranteeing the continuity of the home power supply.

Electric Toy Cars

Electric toy cars require stable and continuous power for actions such as driving, steering, and acceleration. The 2.7V 3000F supercapacitor can provide a long runtime for the toy car and withstand the current surges generated by frequent operation. It ensures a stable power supply, enabling children to enjoy uninterrupted playtime.

Industrial Sensor Nodes

In environmental monitoring sensors on factory production lines, the 2.7V 3000F supercapacitor can act as a backup power source to address short power interruptions or wiring failures. With its large capacity, it ensures that sensors can continue to collect and transmit key data, such as temperature, humidity, and harmful gas concentrations, preventing production accidents.
